Telescopic roller conveyor

Capacity: 450-5687t/h

Chat online

The drum structure can be unpowered, powered, or electric, and can be manually retracted or electrically retracted according to the usage scenario. This equipment can improve loading and unloading efficiency and reduce manual handling distance. It is often used in logistics warehouses, loading platforms, express sorting lines, etc.

Telescopic Roller Conveyor is widely used in: truck/container loading and unloading, logistics express centers, factory workshop entrances and exits

Advantages

Product Advantages and Features

Supports free expansion and contraction of multiple sections

flexible structure, rapid expansion and contraction according to the job site, saving space
Easy to operate, saving manual handling distance

materials can be transported directly into/out of the carriage to improve loading and unloading efficiency
Multiple driving modes available

supports electric rollers, sprockets, unpowered gravity conveying and other forms
Flexible installation and easy movement

can be equipped with casters, foldable and mobile, suitable for different loading and unloading environments
Strong load

bearing capacity and solid structure - can handle different load conditions such as heavy boxes, large items, and bags
Can integrate weighing, scanning, and testing equipment

to meet the needs of intelligent sorting and information collection, and support access to automated operating systems

Better Quality Production

To give you peace of mind

Technical Data

Model	number of sections	scalable length (mm)	drum diameter (mm)	load capacity (kg/m)	driving method	applicable materials
TRC-60/3M-Manual	3	1500–4500	Ø60	≤100	No power (gravity sliding)	Carton, small package
TRC-76/5M-Motorized	4	2000–7000	Ø76	≤300	electric roller+button control	pallet, express box
TRC-89/6M-Heavy	5	2500–8500	Ø89	≤600	Double chain drive + variable frequency speed control	large items, bagged, boxed items

Note: Model-specific details available upon request. Please contact technical support.
